Zweirad Union Motor 802 50 ccm 4-speed and 5-speed repair manual
Image may differ in color or layout
Item Number:
WK-0009
€20
Only the discounted shipping costs will be charged for this item.
In stock and ready for shipping
- Condition:
- New
- Brand:
- DKW, Express, Victoria, Zweirad Union
- Dimensions:
- DIN A5
- Pages:
- 66 pages
- Language:
- German
Description
Two-wheel Union engine type 802 042 (2.6 HP) and 802 052 (4.6 HP), 50 cc 4- and 5-speed foot gears, kick starter and repair instructions for disassembly and assembly of the telescopic fork type 159/139. DKW-VICTORIA-EXPRESS up to 1968.
Contents:
General part
- Technical data - Mounting instructions - Special tools - Mounting stand
- Blower casing
- Flywheel light magneto ignition
- Coupling
- Cylinder head - cylinder - piston
- Motor housing
- Gear shafts - Gear wheels
- Switching sleeve - kick starter shaft
- Gearshift
- Crankshaft
- Bearing of the crankshaft and gear shafts
Contents:
General part
- Technical data - Mounting instructions - Special tools - Mounting stand
- Blower casing
- Flywheel light magneto ignition
- Coupling
- Cylinder head - cylinder - piston
- Motor housing
- Gear shafts - Gear wheels
- Switching sleeve - kick starter shaft
- Gearshift
- Crankshaft
- Bearing of the crankshaft and gear shafts
You will receive a good quality bound book or brochure by postNo PDF, no CD and no loose sheet collection!
