Triumph BDG 250 L, SL, W and Boss spare parts list Spare parts catalog
Image may differ in color or layout
Item Number:
WK-0083
€20
Only the discounted shipping costs will be charged for this item.
In stock and ready for shipping
- Condition:
- New
- Brand:
- Triumph
- Dimensions:
- DIN A5
- Pages:
- 56 pages
- Language:
- German
Description
Spare parts list for Triumph BDG 250 L/SL/W and Boss BDG 250 L/SL valid from reg. no.: 314501, BDG 250 W valid from reg. no.: 321307, Boss valid from reg. no.: 355001. edition 1/1955 with addendum 6/1957, in German.
Plate 1:
Cylinder, piston, block engine housing, crank drive/chain pinion, spark plug, carburetor, intake silencer/air filter.
Table 2:
Carburetor, intake silencer/air filter.
Table 3:
Gearbox cover, gear set, gear shift, gear foot pedal, gear idle indicator, gear idle
indicator, clutch, foot starting system
.
Plate 4:
Frame front part, frame rear part, parking support, rear wheel stand, front wheel stand, fork joint, steering/steering damper, telescopic front fork, rear suspension, fuel tank, luggage rack for fuel tank, fuel pipe, swinging saddle, footrests, pillion ratchets, battery.
Plate 5:
Handlebars/handlebar arms/cables, rear wheel/rear hub, front wheel/front hub, rims/spokes, rear brake; master cylinder insert/sliding shoe brake/devices/wheel cylinder/miscellaneous.
Plate 6:
Front mudguard, rear mudguard, license plate holder (front mudguard), license plate holder (rear mudguard), luggage rack, upper and lower chain guard, toolboxes, exhaust system, battery, battery igniter/headlight, speedometer, horn, tail light, light pipe, low socio caliper.
Plate 7:
Carburetor, intake silencer/air filter, transmission cover, clutch, frame front part, cables, rear hub, front hub, rear brake, fuel tank, battery igniter/headlight, stop light switch.
Plate 8:
Luggage bag holder, passenger seat, handlebars, passenger footrests
